SKF71822ACD/HCP4轴承详细参数
发布时间:2026-04-15| 角接触球轴承, 精密, ACD, contact angle 25°, hybrid, super-precision | |||||||||||
 | |||||||||||
| 主要数据尺寸 | 基本负荷额定值 | 疲劳负荷限值 | 可达到的速度 | 体积 | 型号 | ||||||
| 动态 | 静态 | 当润滑与 | SKF | SNFA | |||||||
| 油脂 | 滴油润滑 | Listing of both SKF and SNFA designations means that | |||||||||
| d | D | B | C | C0 | Pu | ||||||
| |||||||||||
| mm | kN | kN | r/min | kg | - | ||||||
| |||||||||||
| 110 | 140 | 16 | 30,2 | 38 | 1,46 | 9000 | 14000 | 0,453 | 71822 ACD/HCP4 | SEA110 /NS 7CE3 | |
SKF71822ACD/HCP4超精密角接触球轴承P4级供应商
- 八零动力专业销售71822ACD/HCP4超精密角接触球轴承P4级，库存SKF71822ACD/HCP4大量现货，与SKF合作，咨询热线：022-58519723
- SKF71822ACD/HCP4转动世界的精密之选,它的尺寸一致性，让批量生产成为可能 它的密封性能，完美抵御灰尘和杂质的侵袭 它的耐腐蚀性，让它经久不衰 给您意想不到的顺畅体验,性能卓越的它，为机械设备的稳定运行提供了可靠保障,八零动力SKF超精密角接触球轴承P4级品种全，价格优，质量有保证！
