SKFSY1.3/16PF/AH轴承详细参数
发布时间:2026-08-28| Y-型立式轴承座单元, SKF ConCentra, 英制轴承 | ||||||||||||
 | ||||||||||||
| 尺寸 | 基本负荷额定值 | 限制速度 | 体积 | 型号 | ||||||||
| 动态 | 静态 | 轴承单元 | Components (only available as complete units) | |||||||||
| 轴承座 | 轴承 | |||||||||||
| d | A | H | H1 | L | C | C0 | ||||||
| ||||||||||||
| mm | kN | r/min | kg | - | ||||||||
| ||||||||||||
| 30,163 | 40 | 82 | 42,9 | 152 | 19,5 | 11,2 | 6300 | 1,30 | SY 1.3/16 PF/AH | SY 506 U/AH | YSP 206-103-2F/AH | |
SKFSY1.3/16PF/AHY-轴承座单元供应商
- 八零动力专业销售SY1.3/16PF/AHY-轴承座单元，库存SKFSY1.3/16PF/AH大量现货，与SKF合作，咨询热线：022-58519723
- SKFSY1.3/16PF/AH坚固的结构稳定的性能它的加工设备，代表了世界领先水平 承载重载历经岁月该轴承的性能优越，极大地提高了设备的工作效率引领转动新潮流,有效增强了机械设备的竞争力,八零动力SKFY-轴承座单元品种全，价格优，质量有保证！
